DIY Cold Plunge Kit with Active Aqua Chiller
In stockRegular price From $999.95 USDSale price From $999.95 USD Regular priceUnit price per$1,199.95 USD -
DIY Cold Plunge Quick Connect Kit with Active Aqua Chiller
In stockRegular price From $1,099.95 USDSale price From $1,099.95 USD Regular priceUnit price per$1,299.95 USD
Complete Build Kit vs Quick Connect Kit
| Complete Build Kit + Chiller | Quick Connect Kit + Chiller | |
|---|---|---|
| Price | From $999.95 | From $1,099.95 |
| Plumbing | Glued 3/4 inch PVC | 3/4 inch quick connect fittings, no glue or primer |
| Install time | 1 to 3 hours, plus PVC cure time | About 1 hour, including drilling and leak testing |
| Take it apart later | No, glued joints are permanent | Yes, fittings release by hand |
| Pump, ozone and filtration | Same in both: Danner Aqua-Mag 1200 pump, Ambohr SPA-124 ozone, 10 inch filter housing with two 50 micron cartridges | |
| Chiller | Active Aqua 1/4, 1/2 or 1 HP with the matching connections | |
| Best for | A permanent setup at the lowest price | Moving, reconfiguring or storing the plunge for winter |
| Shop the Complete kit | Shop the Quick Connect kit | |
Which Active Aqua Chiller Size Do You Need?
| Chiller | Cooling | Rated tub size | Best for |
|---|---|---|---|
| 1/4 HP | 3,010 BTU/hr | 40 to 92 gal | Barrels and small tubs, rotomolded coolers like a Grizzly 450, indoors or in mild climates |
| 1/2 HP | 4,020 BTU/hr | 90 to 130 gal | 100 gallon stock tanks, insulated tubs under 130 gallons and not in a hot climate over 85°F. If in a warmer climate or your tub is not insulated we recommend the 1HP chiller |
| 1 HP | 10,050 BTU/hr | 80 to 250 gal | Chillers in a space over 85°F, several daily users, or tubs over 130 gallons. |
Outdoors, an insulated cover does more for run time than a bigger chiller.
Cold Plunge Builder
Build your cold plunge setup in 60 seconds
Answer a few quick questions about your tub and climate. We will match the chiller, the plumbing kit and the add-ons, then put it all in your cart.
Loading the chiller finder
What Else You Need
The bundle covers the plumbing, pump, ozone, filtration and chiller. Here is what you bring:
- A tub. A Rubbermaid 100 or 150 gallon stock tank from Tractor Supply or a farm store, or any tub with a flat wall up to 1 1/2 inches thick for the bulkheads.
- An insulated cover. Optional, but outdoors it does more for run time than a bigger chiller. Shop insulated covers.
- A GFCI protected 120V outlet within reach of the chiller. No extension cords.
- A covered spot for the chiller. Out of open rain and direct sun, with 12 inches of clearance on the sides and 18 inches behind it.
- A drill and hole saw for the bulkhead holes. Your build guide lists the exact sizes and the rest of the tools for your kit.
